Membrane structure PVC fabric is a high - performance material widely utilized in modern architectural and engineering applications, renowned for its durability, versatility, and aesthetic appeal. The most popular specs are 900gsm,1100gsm and 1250gsm.
| Item No: | Descriptions | Unit | Your Product Measurements: | |
| 1 | Material of the Woven Fabric DIN60001 | Polyester | ||
| 2 | Weave DIN ISO 9354 | |||
| 3 | Count of Yarn | warp: | dtex | 1300 |
| weft: | dtex | 1300 | ||
| 4 | Setting/ Number of ThreadsDIN EN 1049 | warp: | threads/inch | 30 |
| weft: | threads/inch | 32 | ||
| 5 | Base Coat | PVC | ||
| 6 | Weight of the cloth DIN EN 12127 | g/m² | 353 | |
| 7 | Total Weight DIN EN ISO-2286-2 | g/m² | 1100 | |
| 8 | Tensile Strength DIN 53354 | warp: | N/5cm | 500 |
| weft: | N/5cm | 4850 | ||
| 9 | Tear Resistance DIN 53363 | warp: | N | 550 |
| weft: | N | 500 | ||
| 10 | Adhesion (Coating) DIN 53357 | N/5cm | 180 | |
| 11 | Adhesion (Welding) | kg/5cm | 15 | |
| 12 | FR | B2/B1/M2/M1/NFPA701 | ||
| 13 | UV Stability | yes | ||
| 14 | Surface treatment | Acrylic/PVDF | ||
